Single Projected - I f you would like to manually set the CRS from a list of pre-defined systems using the Search Coordinate System Dialog.

Set the Project Coordinate System (CRS):.

The Survey Type and Description boxes can be used to add additional notes about the project.

By default, the folder for your project will be in the 'C:\Users\username\QPS-Data\' directory, though you can choose another location.

Īlternatively, you can create a project by clicking the Create Project Button on Qimera's Bathymetry Toolbar, or by going to the P roject Menu and choosing New Project. How-to Bring Hypack HSX Data Into Qimeraġ) After you open Qimera, the Projects Dialog will launch. To view your license coverage in Qimera, go to the Help Menu and choose Show License Manager. The import and processing of raw data formats is dependent on licensing. Useful information about what is read from HSX files on import can be found on the Qimera Supported Data Formats page, the Add Raw Sonar Files Dialog page and the Sonar Source Data Import Capabilities page. They are binary files and can be loaded in Qimera as Processed Point Files using the Add Processed Point Files Dialog. HS2 and HS2X format files are Hypack files that have had some level of processing applied to them. It is important to note that the projected CRS information (which CRS was used during acquisition) is not stored in the HSX file directly and must be known and supplied by the user. The CRS of the files should be considered when being added to a project.

HSX files are always in a projected Coordinate Reference System (CRS). HSX files are in an ASCII format and can be loaded into a text editor when troubleshooting. The supported Raw Sonar Files for Hypack is a HSX file. The data was provided by the Port of London Authority. The data used for this How-to is single head Reson 8125 data logged using Hypack.
